Product Summary
The IXFN44N50 is a Power MOSFET. The applications of the device include DC-DC converters, Synchronous rectification, Battery chargers, Switched-mode and resonant-mode power supplies, DC choppers and Temperature and lighting controls.
Parametrics
IXFN44N50 absolute maximum ratings: (1)VDSS: 500 V; (2)VDGR: 500 V; (3)VGS: ±20 V; (4)VGSM: ±30 V; (5)ID25: 44 A; (6)IDM: 176 A; (7)IAR: 24A; (8)EAR: 30mJ; (9)dv/dt: 5 V/ns; (10)PD: 520 W; (11)TJ: -55 to +150℃; (12)TJM: 150℃; (13)Tstg: -55 to +150℃.
Features
IXFN44N50 features: (1)International standard packages; (2)Molding epoxies meet UL 94 V-0 flammability classification; (3)SOT-227B miniBLOC with aluminium nitride isolation; (4)Low RDS (on) HDMOSTM process; (5)Unclamped Inductive Switching (UIS) rated; (6)Fast intrinsic rectifier.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 IXFN44N50 |
Ixys |
MOSFET 500V 44A |
Data Sheet |
Negotiable |
|
||||
 |
IXFN44N50Q |
Ixys |
MOSFET 44 Amps 500V 0.12 Rds |
Data Sheet |
Negotiable |
|
||||
|
IXFN44N50U2 |
|
MOSFET N-CH 500V 44A SOT-227B |
Data Sheet |
Negotiable |
|
||||
|
IXFN44N50U3 |
|
MOSFET N-CH 500V 44A SOT-227B |
Data Sheet |
Negotiable |
|
||||
