Product Summary

The SN74LS32DR is a quadruple 2-input positive-or gate. The device contains four indempendent 2-input OR gates. The SN74LS32DR is characterized for operation from 0 to 70℃.

Parametrics

SN74LS32DR absolute maximum ratings: (1)supply voltage, VCC: 7V; (2)input voltage: 7V; (3)operating free-air temperature: 0 to 70℃; (4)storage temperature range: -65 to 150℃.

Features

SN74LS32DR features: (1)package options include plastic small outline packages, ceramic chip cariers and flat packages, and plastic and ceramic DIPs; (2)dependable texas instruments quality and reliability.

Diagrams

SN74LS32DR schematic diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SN74LS32DR
SN74LS32DR

Texas Instruments

Gates (AND / NAND / OR / NOR) Quad 2-input Positive-OR gates

Data Sheet

0-1: $0.40
1-25: $0.37
25-100: $0.26
100-250: $0.22
SN74LS32DRE4
SN74LS32DRE4

Texas Instruments

Gates (AND / NAND / OR / NOR) Quad 2-input Positive-OR gates

Data Sheet

0-1: $0.34
1-25: $0.27
25-100: $0.23
100-250: $0.20
SN74LS32DRG4
SN74LS32DRG4

Texas Instruments

Gates (AND / NAND / OR / NOR) Quad 2-input Positive-OR gates

Data Sheet

0-1: $0.34
1-25: $0.27
25-100: $0.23
100-250: $0.20
